# 某海外电商app设备指纹收集与加密算法分析

最近好像比较流行用ai水文章，我也用ai水几篇。这份是用ai自动分析了某电商的设备指纹函数trace。将3GB的trace文件交给ai自动分析后的结果。

我只使用[QTrace](https://bbs.kanxue.com/thread-290574.htm)对关键的指纹收集函数做trace，然后将trace文件直接交给ai自动分析，其余的不做干预。总共分析了不到20分钟
![图片描述](upload/attach/202610/872365_J63RKGH2TV3B44S.webp)
报告包含完整的指纹采集点，源码级实现逻辑，和数据加密方式。

## 报告说明

本报告中的结论分为三类：

1. **运行时直接观察**：来自 QBDI trace 中的 JNI、libc、字符串和内存操作。
2. **静态确认**：来自 `libriver.so` ARM64 反汇编，以及 APK 中 `ri.bg`、`s13.c` 等 Java 类反编译。
3. **未完整覆盖的上游输入**：trace 仅记录到最终值，但没有覆盖其 producer。源码通过 `AppInputs` 明确接入，绝不使用猜测逻辑冒充原实现。

所谓“源码级等价实现”，指在相同 Android 版本、相同应用 UID、相同私有数据、相同运行时 block list 和相同实时设备状态下，按 trace 观察到的 API、顺序、格式及编码方式重现采集。时间、随机数、内存、电池、网络、sequence 和密文按设计会随会话变化。

---

## 1. 样本与结论

- Trace：`D:\tomu\tomu_env_9.trace`，3,645,346,354 字节，QBDI ARM64 逐指令 trace。
- 对应 native 模块：`D:\tomu\tomu\split_config.arm64_v8a\lib\arm64-v8a\libriver.so`
- SHA-256：`2774ae72fd2c42a0857942a1fe187e46f807d4ee61dfe38dcdbbbbc81d297e08`
- trace 入口配置：`D:\tomu\tea_trace\nativelib\src\main\cpp\native_main.cpp:91`，`trace_func = 0x2604ac`。
- 最终明文是 URL query-string；加密结果是一个二进制信封，经标准 Base64 后包装为：

```json
{"encryptedData":"<standard-base64>"}
```

本次实际结果：Base64 长 14,500，解码后 10,873 字节。

**加密算法链已经可以确定为：随机临时密钥材料 + 32 字节共享秘密派生 + SHA-256/HMAC/HKDF 类 KDF + ChaCha20-Poly1305 风格 AEAD 信封。** 最后一层的结构与长度关系完全吻合 `12-byte nonce + ciphertext + 16-byte tag`；加密数据不是 AES 分组密文（总长不是 16 的倍数）。

> 注意：该包高度控制流混淆，静态伪代码中的函数名均为本文按行为命名。算法流程和长度关系为高置信度；固定服务端公钥/协议常量仍应从当前版本运行时内存提取，而不能凭空写死。

---

## 2. 两层明文组装

### 2.1 第一层：`p1`～`p21`

实际顺序严格为：

```text
p1=...&p2=...&p3=...&p4=...&p5=...&p6=...&p7=...&p8=...&p9=...
&p10=...&p11=...&p12=...&p13=...&p14=...&p15=...&p16=...
&p17=...&p18=...&p19=...&p20=...&p21=...
```

每个值先按 `application/x-www-form-urlencoded` 规则转义（空格变 `+`，保留字符按 UTF-8 `%HH` 编码），再以 `&` 连接。

| 参数 | 本次值/含义 | 具体采集方法 |
|---|---|---|
| `p1` | `{"vInfo":{"exits":0,"id":""},"systemService":"[]"}` | `android.os.ServiceManager.listServices()`；结合厂商/虚拟化关键字检查。trace 中枚举了 284 个 service，并逐个与 `oppo/miui/vivo/.../xposed/libsu` 等比较。|
| `p2` | `tomu_secure_v2` Android Keystore 证书链，4 张证书以 `;` 拼接 | `KeyStore.getInstance("AndroidKeyStore")` → `load(null)` → `containsAlias("tomu_secure_v2")` / 回退 `tomu_secure` → `getCertificateChain()` → 每张 `X509Certificate.getEncoded()` → Base64。|
| `p3` | `-4` | 通过 `ServiceManager.getService("package")` 及 `IPackageManager.Stub.TRANSACTION_isFirstBoot` 等系统状态检测所得状态码。|
| `p4` | JSON，键 `1` 为 `/proc/version`，键 `2` 为 `uname -a` | 读取内核版本；trace 明确执行 `uname -a`。|
| `p5` | 空 | 本次未取得。|
| `p6` | 空 | 本次未取得。|
| `p7` | 空 | 本次未取得。|
| `p8` | `429` | `Settings.Global/Secure.getString(contentResolver, "boot_count")`。|
| `p9` | `中國移動香港 China Mobile HK` | SIM/运营商信息。|
| `p10` | `3240a81b31837bae` | `ContentResolver.call(content://settings/secure, "GET_secure", "android_id", null)`，再从 Bundle 取 `value`。|
| `p11` | 空 | 本次未取得。|
| `p12` | `包名|标签|签名摘要|版本码|flags` | `Telephony.Sms.getDefaultSmsPackage()`；PackageManager 查询默认短信应用；`Signature.toCharsString()` 后调用 Java `ri/bg.dg(...)` 得到 `C2C258...` 摘要；本次为 Google Messages。|
| `p13` | `Built-in Screen|null;` | `DisplayManager.getDisplays()`、`Display.getName()`；反射 `Display.mDisplayInfo.ownerPackageName`。|
| `p14` | `null` | 当前包名及 `PackageManager.getInstallerPackageName()`；本次安装来源为空。|
| `p15` | `900063915` | 安装来源/包环境派生的整数标识；trace 能确认其位置和值，当前证据不足以给该整数命名为某个公开 Android 字段。|
| `p16` | 六类音量 JSON | `AudioManager.getStreamMinVolume/getStreamMaxVolume/getStreamVolume`，包含 `voiceCall/system/ring/music/alarm/notification`。|
| `p17` | `en_CA` | Resources → Configuration → LocaleList → 首个 Locale 的 language/country。|
| `p18` | `Asia/Shanghai GMT+08:00` | `TimeZone.getDefault().getID()` 和 `getDisplayName()`。|
| `p19` | 空 | 尝试反射 `com.android.internal.os.PowerProfile.sPowerItemMap`，本次无值。|
| `p20` | `SM7250` | SoC/硬件平台信息。|
| `p21` | 空 | 查询 `Settings` 的 `ad_aaid`，本次为空。|

### 2.2 第二层：主环境 query

第一层整体又作为一个字段嵌入第二层。trace 中完整观察到以下字段与顺序：

```text
version=35
process_id=8484
availablecapacity=78084268032
input_device=4|sec_touchscreen|0fa9d3d0d40f7f5b316320876742e00ad5eb1ba9|4355;
machine_arch=ARM
fk_result={"vInfo":{"exits":0,"id":""},"antInfo":{"exits":0}}
0c1999=
foreground=true
uuid=5951dc94-f0fc-45ee-a235-9befbeb1f365
secure_lock=0
totalcapacity=117153181696
mediaDrm=0:07c0...a2af1|Google|17.0.0|Widevine CDM;
c86fee=4.61.0
instrumentation=android.app.Instrumentation
u2=<另一个已加密并 Base64 的大字段>
ab9de2=1
060a12=
net_type=WIFI
01bf33=
currentTime=1784689721004
availablememory=3429867520
brightness=44
a5=1
74b954=36
kernelVersion=<Linux /proc/version>
eeba5e=en
02b81e=Asia/Shanghai
dme=1
```

随后继续追加：

| 字段 | 实际内容/采集方式 |
|---|---|
| `platform_type` | `1` |
| `sharedpreference_id` | `SharedPreferences("se_config").getString("secure_sharedpreference_id", "")`；本次 `1cda03acb0484d718ac373ad6cd91475`。|
| `dpi` | `DisplayMetrics.densityDpi`；本次 440。|
| `resolution` | `widthPixels + "x" + heightPixels`；本次 `1080x2340`。|
| `uid` | 当前 UID/派生值；本次为空。|
| `cookie` | 本次 `Cm3AFGpE44VWp0sh8sa0Ag==`，24 字符标准 Base64，解码 16 字节。|
| `root` | 检查 `/product/bin/su`、`/sbin/su`、`/system/bin/su`、`/system/sbin/su`、`/system/xbin/su`、`/vendor/bin/su`；并检查 `/data/misc/riru`。|
| `fingerprint` | `Build.FINGERPRINT`；本次 `google/redfin/redfin:14/UP1A.../release-keys`。|
| `build_id` | `UP1A.231105.001.B2`。|
| `rom_status` | ROM/启动状态。|
| `cpuinfo` | CPU 硬件信息；本次可见 `Qualcomm Technologies, Inc LITO`。|
| `input_mathod` | `Settings.Secure["default_input_method"]`，本次 Google LatinIME。|
| `battery_status` | 注册 `ACTION_BATTERY_CHANGED`，遍历 extras 全部键值；含 technology、health、status、plugged、present、charge_counter、level、scale、temperature、voltage、cycle count 等。|
| `install_time` | PackageInfo.firstInstallTime。|
| `app_update_time` | PackageInfo.lastUpdateTime。|
| `boot_time` | `/proc/sys/kernel/random/boot_id` 及系统时间/文件时间组合。|
| `ip_list` | 枚举 `NetworkInterface`，仅取 up 的接口，再枚举非 loopback 地址；本次包括 rmnet_data0/dummy0/wlan0 的 IPv6 和 wlan0 IPv4。|
| `total_memory` | `/proc/meminfo`；本次 `7823970304`。|
| `sequence` | 本次 0。|
| `local_sequence` | `SharedPreferences("se_config")["secure_local_sequence_id"]`，取出后递增并 `apply()`；本次送出 627。|
| `did_info` | 多个时间、文件状态、boot/device ID 等以 `;` 拼接并 URL 编码。|
| `simState` | SIM 状态；本次 0。|
| `bgid` | 设备/业务标识，本次为空。|

此外还观察到：

- 可用/总存储、可用内存；
- 屏幕亮度；
- 当前前后台；
- 网络类型；
- MediaDrm Widevine vendor/version/description 和设备 ID 摘要；
- 输入设备列表及 descriptor/vendor/product；
- 当前 Instrumentation 类；
- Root/Riru/Xposed/ROM 厂商痕迹；
- 包安装、默认短信应用、显示设备、音量、区域、时区、SoC、内核信息。

---

## 3. 明文组装的准确逻辑

```cpp
string form_encode(const vector<pair<string,string>>& fields) {
    string out;
    for (size_t i = 0; i < fields.size(); ++i) {
        if (i) out += '&';
        out += url_encode(fields[i].first);  // 字段名本身通常无需变化
        out += '=';
        out += url_encode_utf8(fields[i].second); // 空格 -> '+'，其余按 %HH
    }
    return out;
}

string build_p_block() {
    // 必须保持 p1 ... p21 的原始顺序；空值仍输出 key=
    return form_encode({
        {"p1", collect_service_and_virtualization()},
        {"p2", collect_keystore_cert_chain()},
        {"p3", collect_first_boot_state()},
        {"p4", collect_kernel_json()},
        {"p5", ""}, {"p6", ""}, {"p7", ""},
        {"p8", settings_boot_count()},
        {"p9", sim_operator_display()},
        {"p10", android_id_via_content_resolver_call()},
        {"p11", ""},
        {"p12", default_sms_package_record()},
        {"p13", display_record()},
        {"p14", installer_package_or_null()},
        {"p15", installer_environment_code()},
        {"p16", audio_stream_json()},
        {"p17", locale_language_country()},
        {"p18", timezone_id_and_name()},
        {"p19", power_profile_info()},
        {"p20", soc_model()},
        {"p21", settings_ad_aaid()}
    });
}

string build_plaintext() {
    vector<pair<string,string>> f;
    // 按 trace 中固定顺序 push version ... dme
    // 再 push platform_type ... bgid；空值不能省略。
    // 某些复杂子结构先自行用 |、;、, 拼接，再作为一个整体 URL 编码。
    return form_encode(f);
}
```

这里最重要的是：**顺序固定、空字段保留、复杂字段先内部拼接后整体 URL 编码**。改变顺序或省略空字段会改变最终密文和服务端解释。

---

## 4. 加密信封

### 4.1 二进制布局

trace 显示明文加密前长度为 `0x2A1B = 10779` 字节；固定/AAD 头长度为 `0x52 = 82` 字节。最终长度：

```text
82 + 12 + 10779 + 16 = 10873
```

与实际 Base64 解码后的 10,873 字节完全一致。因此布局为：

```text
offset  size                 含义
0       82                   protocol header / AAD
82      12                   AEAD nonce
94      plaintext_length     ciphertext（与明文等长）
94+N    16                   authentication tag
```

`sub_2D9794`（`0x2D9794`）直接给出组包公式：

```cpp
out_len = plaintext_len + 16 + aad_len + 12;
out = new byte[out_len];
AEAD_encrypt(key32, plaintext, plaintext_len,
             aad82, 82, nonce12, ciphertext_and_tag);
memcpy(out, aad82, 82);
memcpy(out + 82, nonce12, 12);
memcpy(out + 94, ciphertext_and_tag, plaintext_len + 16);
```

### 4.2 82 字节 header 的内部布局

`sub_2EBF5C`（`0x2EBF5C`）逐字节构造：

```text
0x00  2   协议版本/算法标记（两个固定字节）
0x02 32   临时公钥/公钥材料 A
0x22 32   随机 salt/公钥材料 B
0x42  8   64 位时间/随机数，按固定端序写入
0x4A  8   调用方传入的 64 位请求标识
总计 0x52 (82)
```

对应伪代码：

```cpp
header[0] = PROTOCOL_BYTE_0;
header[1] = PROTOCOL_BYTE_1;
memcpy(header + 2,  ephemeral_public_or_material_A, 32);
memcpy(header + 34, random_salt_or_material_B,       32);
store_u64_protocol_endian(header + 66, generated_u64);
memcpy(header + 74, &request_id_u64, 8);
```

### 4.3 密钥派生

`sub_2EBF5C` 的数据流：

1. `sub_EABBC(..., 32)` 从安全随机源生成 32 字节临时私钥/随机数；trace 同时观察到 `/dev/urandom`。
2. `sub_E0544` 从该 32 字节值计算 32 字节公钥材料。
3. `sub_E0D40` 用该临时私钥和调用方传入的 32 字节公钥计算 32 字节共享秘密。这组 32-byte 输入/输出及调用关系符合 X25519/ECDH 类交换。
4. 再生成 32 字节随机 salt。
5. `sub_2EC39C` → `sub_EA4AC` / `sub_EA7D4`，基于 SHA-256/HMAC 状态把共享秘密和 salt 派生成最终 32 字节 AEAD key，行为符合 HKDF-SHA256 的 extract/expand。

```cpp
uint8_t eph_private[32] = secure_random_32();
uint8_t eph_public[32]  = x25519_public(eph_private);
uint8_t shared[32]      = x25519(eph_private, server_public_key);
uint8_t salt[32]        = secure_random_32();
uint8_t key[32]         = hkdf_sha256(shared, salt, /*info=*/empty, 32);
```

### 4.4 AEAD 及 Base64/JSON

```cpp
vector<uint8_t> encrypt_envelope(
    bytes plaintext,
    uint64_t request_id,
    bytes32 server_public_key)
{
    bytes32 sk   = secure_random_32();
    bytes32 pub  = x25519_public(sk);
    bytes32 salt = secure_random_32();
    bytes32 ss   = x25519(sk, server_public_key);
    bytes32 key  = hkdf_sha256(ss, salt, {}, 32);

byte aad[82];
    aad[0] = PROTOCOL_BYTE_0;
    aad[1] = PROTOCOL_BYTE_1;
    memcpy(aad + 2, pub, 32);
    memcpy(aad + 34, salt, 32);
    store_u64_protocol_endian(aad + 66, generated_u64());
    memcpy(aad + 74, &request_id, 8);

byte nonce[12] = secure_random_12();
    auto [ciphertext, tag16] = chacha20_poly1305_encrypt(
        key, nonce, plaintext, /*AAD=*/aad);

return concat(aad, nonce, ciphertext, tag16);
}

string final_result =
    "{\"encryptedData\":\"" + base64_standard(envelope) + "\"}";
```

`sub_150144` / `sub_14EAC0` 是标准 Base64 编码路径；trace 最终明确按 `"encryptedData":"` + Base64 + `"}` 组装。

---

## 5. 可复核的关键函数地址

| 地址 | 本文命名 | 作用 |
|---|---|---|
| `0x2EAB50` | top-level encrypt | 调用密钥协商、AEAD、Base64。|
| `0x2EBF5C` | build crypto context/header | 生成临时密钥、共享秘密、salt、82-byte header。|
| `0x2EC39C` | derive key | 调用 HMAC/HKDF 路径生成 32-byte key。|
| `0xEABBC` | secure random | 生成随机字节。|
| `0xE0544` | public-key derivation | 32-byte 私钥 → 32-byte 公钥材料。|
| `0xE0D40` | shared-secret | 32-byte × 32-byte → 32-byte 共享秘密。|
| `0xEA4AC` / `0xEA7D4` | HMAC/HKDF | SHA-256/HMAC 状态与 32-byte 输出。|
| `0x2D9794` | AEAD envelope | 12-byte nonce、16-byte tag、AAD 前缀组包。|
| `0xD9E38` | AEAD core wrapper | 对明文执行认证加密。|
| `0x150144` / `0x14EAC0` | Base64 | 二进制信封编码为标准 Base64。|

---

## 6. 准确性边界

已由 trace **直接观察并确认**：字段名称、字段顺序、大部分字段值、JNI/系统 API、URL 编码后的两层明文、明文长度、82/12/16 字节结构、最终 Base64 和 JSON 包装。

由反汇编与长度关系**高置信度识别**：X25519/ECDH 类 32-byte 密钥交换、HKDF-SHA256 类派生、ChaCha20-Poly1305 风格 AEAD。

当前证据中不能负责任地写死：两个协议字节、服务端长期公钥、header 两个 32-byte 槽位的官方字段名，以及少数混淆字段（如 `p15`）的官方业务命名。它们随版本/会话变化，正确实现应从调用参数和运行时产生，而不是复制本次样本值。

---

# 逐字段源码实现映射

## p1–p21

| 字段 | Java 等价实现 |
|---|---|
| p1 | `collectP1ServiceProbe()`：反射 `ServiceManager.listServices()`，按 trace 中关键字扫描，生成带 `exits` 拼写的 JSON。|
| p2 | `collectP2KeyStoreChain()`：读取 `AndroidKeyStore` 的 `tomu_secure_v2`，回退 `tomu_secure`，证书 DER 标准 Base64 后用 `;` 连接。|
| p3 | `AppInputs.p3()`：trace 只覆盖结果 `-4`，未覆盖其完整 Binder producer，不伪造。|
| p4 | `collectP4KernelJson()`：`/proc/version` 与 `uname -a`。|
| p5/p6/p7 | `AppInputs`；样本为空。|
| p8 | `getSetting(...,"boot_count")`。|
| p9 | `AppInputs.simOperatorDisplay()`；样本为运营商显示文本，但 trace 未覆盖其上游 Telephony 调用。|
| p10 | `getAndroidIdViaProviderCall()`，与 trace 的 `content://settings/secure` / `GET_secure` / `android_id` / `value` 一致。|
| p11 | `AppInputs.p11()`；样本为空。|
| p12 | `collectDefaultSms()`；默认短信包、label、`MD5(Signature.toCharsString UTF-8)` 大写十六进制、version、flags。|
| p13 | `collectDisplays()`；DisplayManager、名称、反射 `mDisplayInfo.ownerPackageName`。|
| p14 | `getInstallerPackage()`。|
| p15 | `AppInputs.p15()`；样本值 900063915，但 producer 未在 trace 覆盖。|
| p16 | `collectAudioJson()`；六个 AudioManager stream 的 min/max/current。|
| p17 | `collectLocale()`。|
| p18 | `collectTimeZone()`。|
| p19 | `AppInputs.p19PowerProfile()`；trace 尝试 hidden `PowerProfile.sPowerItemMap`，样本为空。|
| p20 | `collectSoc()`；优先 `Build.SOC_MODEL`，回退系统属性。|
| p21 | `getSetting(...,"ad_aaid")`。|

每个 `pN` 在 native 执行前还通过 APK 方法 `ri.bg.cb("pN")` 查询运行时 block list。调用者如需精确复现字段屏蔽，应在 `buildPBlock` 前应用同一 block list。

## Java 主 query

| 字段 | Java 等价实现/来源 |
|---|---|
| version | `Build.VERSION.SDK_INT` |
| process_id | `Process.myPid()` |
| availablecapacity | `StatFs(data).getAvailableBytes()` |
| input_device | `collectInputDevices()` |
| machine_arch | `Build.SUPPORTED_ABIS[0]` 归一为 ARM/X86 |
| fk_result | `AppInputs.fkResult()` |
| 0c1999 | `AppInputs.field0c1999()` |
| foreground | `ActivityManager.getMyMemoryState()` |
| uuid | `AppInputs.uuid()`，必须是 Tomu 持久化 UUID，不是临时随机 UUID |
| secure_lock | `KeyguardManager.isDeviceSecure()` |
| totalcapacity | `StatFs(data).getTotalBytes()` |
| mediaDrm | `collectWidevine()`：Widevine deviceUniqueId SHA-256 小写 hex、vendor/version/description |
| c86fee | 当前 app versionName |
| instrumentation | `ActivityThread.mInstrumentation.getClass().getName()` |
| u2 | `AppInputs.u2()`，独立加密 token producer 不在本 trace |
| ab9de2 | 常量 `1` |
| 060a12 | `AppInputs.field060a12()` |
| net_type | `ConnectivityManager` / `NetworkCapabilities` |
| 01bf33 | `AppInputs.field01bf33()` |
| currentTime | `System.currentTimeMillis()` |
| availablememory | `ActivityManager.MemoryInfo.availMem` |
| brightness | `Settings.System.SCREEN_BRIGHTNESS` |
| a5 | `AppInputs.fieldA5()` |
| 74b954 | `AppInputs.field74b954()` |
| kernelVersion | `/proc/version` |
| eeba5e | `Locale.getDefault().getLanguage()` |
| 02b81e | `TimeZone.getDefault().getID()` |
| dme | `AppInputs.dme()` |

## Native 后续字段（trace 中的实际顺序）

| 字段 | Java 等价实现/来源 |
|---|---|
| platform_type | 常量 `1` |
| sharedpreference_id | `se_config/secure_sharedpreference_id` |
| dpi | `DisplayMetrics.densityDpi` |
| resolution | `widthPixels + "x" + heightPixels` |
| uid | `AppInputs.uidField()` |
| cookie | `AppInputs.cookie()` |
| cpuinfo | `/proc/cpuinfo` Hardware/model name |
| build_id | `Build.ID` |
| fingerprint | `Build.FINGERPRINT` |
| battery_status | `collectBattery()`：ACTION_BATTERY_CHANGED extras 的 `key,value,` 串 |
| boot_time | `collectBootInfo()`；当前实现覆盖明确观察到的 boot_id，完整复合值属于 did/文件状态路径 |
| root | `collectRoot()`：su/Riru 文件检查 |
| rom_status | `AppInputs.romStatus()` |
| install_time | `PackageInfo.firstInstallTime` |
| app_update_time | `PackageInfo.lastUpdateTime` |
| input_mathod | `Settings.Secure.DEFAULT_INPUT_METHOD`，字段拼写故意保留 |
| ip_list | `collectIpList()`：up interface、非 loopback 地址，`;` 结尾 |
| total_memory | `/proc/meminfo` MemTotal × 1024 |
| sequence | `AppInputs.sequence()` |
| local_sequence | `nextLocalSequence()`：读当前值、写 `current+1`、返回当前值 |
| did_info | `AppInputs.didInfo()`；trace 显示复合值，但未覆盖所有 producer |
| simState | `TelephonyManager.getSimState()` |
| bgid | `AppInputs.bgid()` |

## 为什么部分字段必须作为输入

“能编译”不等于“准确”。对 trace 没有执行到 producer 的字段，写一个看似合理的 Android API 会制造错误结论。因此源码把这些字段显式定义成 `AppInputs`：调用方必须接入原始 Tomu 模块或继续针对相应 producer 补 trace。这样已观察到的采集逻辑可以完全重现，而未知项不会被伪造。

---

# 复现工程使用与限制

## Files

- `EnvCollector.java`: source-level Java equivalents for every field whose producer is observable in `tomu_env_9.trace`.
- `../tomu_env_9_analysis.md`: field inventory, native encryption call graph and evidence notes.

The source was compiled successfully against Android API 37's `android.jar`.

## Usage

```java
EnvCollector.AppInputs appInputs = new EnvCollector.Defaults() {
    @Override public String uuid() { return loadTomuPersistedUuid(); }
    @Override public String u2() { return generateU2(); }
    @Override public String cookie() { return loadCookie(); }
    @Override public String p15() { return calculateP15(); }
    @Override public String didInfo() { return buildDidInfo(); }
};

String pBlock = EnvCollector.buildPBlock(context, appInputs);
String main = EnvCollector.buildMainQuery(context, appInputs);
String plaintext = EnvCollector.appendNativeFields(context, main, appInputs);
```

`pBlock` is a separate collected block seen in the trace. Its placement inside the product's higher-level request is controlled by the caller. The final native plaintext in this trace is the `main` query followed by the native fields in `appendNativeFields`.

## Exactness boundary

A different application cannot completely reproduce Tomu's values merely by calling public Android APIs:

1. `tomu_secure_v2`, `se_config`, the UUID, cookie, `u2`, and related IDs are private to Tomu's UID/data directory.
2. Package visibility and hidden-API policy change the service/package/display results.
3. `ri.bg.cb(field)` can suppress individual `pN` fields using a runtime block list supplied elsewhere in the app.
4. `p3`, `p15`, `u2`, `cookie`, `did_info`, `rom_status`, `sequence`, `bgid`, and several obfuscated fields are supplied by other app/native subsystems. The trace contains their values but does not contain enough producer execution to reconstruct those producers accurately. They are explicit `AppInputs`, rather than fabricated implementations.
5. Time, memory, battery, storage, IP, random, sequence and cryptographic values are intentionally session-dependent.

For exact same-device reproduction, execute this code in the original app process/UID and provide the `AppInputs` from the original app modules. Otherwise, the methods reproduce collection semantics but values legitimately differ.

## Important corrected details

- `p12` signature hash is **MD5 of `Signature.toCharsString()` UTF-8 bytes**, uppercase hex. This follows APK class `ri.bg.dg -> s13.c.b`, not MD5 of raw certificate bytes.
- URL encoding uses Java `URLEncoder` behavior: UTF-8, space to `+`, percent encoding with uppercase hex.
- Empty fields are emitted.
- Field order is protocol-significant and represented explicitly in source.
- Battery extra order follows `Bundle.keySet().iterator()` exactly as observed; Android does not promise this order across versions.

---

# 完整 Java 源码：`EnvCollector.java`

以下代码不是摘要，而是报告对应的完整可编译采集实现。已使用 Android API 37 的 `android.jar` 编译验证。

```java
package tomu.reproduction;

import android.app.ActivityManager;
import android.app.Application;
import android.app.KeyguardManager;
import android.content.ContentResolver;
import android.content.Context;
import android.content.Intent;
import android.content.IntentFilter;
import android.content.SharedPreferences;
import android.content.pm.ApplicationInfo;
import android.content.pm.InstallSourceInfo;
import android.content.pm.PackageInfo;
import android.content.pm.PackageManager;
import android.content.pm.Signature;
import android.hardware.display.DisplayManager;
import android.media.AudioManager;
import android.media.MediaDrm;
import android.net.ConnectivityManager;
import android.net.Network;
import android.net.NetworkCapabilities;
import android.net.Uri;
import android.os.BatteryManager;
import android.os.Build;
import android.os.Bundle;
import android.os.Debug;
import android.os.Environment;
import android.os.LocaleList;
import android.os.Process;
import android.os.StatFs;
import android.provider.Settings;
import android.provider.Telephony;
import android.util.Base64;
import android.util.DisplayMetrics;
import android.view.Display;
import android.view.InputDevice;
import android.view.WindowManager;

import org.json.JSONObject;

import java.io.BufferedReader;
import java.io.ByteArrayOutputStream;
import java.io.File;
import java.io.FileInputStream;
import java.io.InputStream;
import java.io.InputStreamReader;
import java.lang.reflect.Field;
import java.lang.reflect.Method;
import java.net.InetAddress;
import java.net.NetworkInterface;
import java.net.URLEncoder;
import java.nio.charset.StandardCharsets;
import java.security.KeyStore;
import java.security.MessageDigest;
import java.security.cert.Certificate;
import java.util.ArrayList;
import java.util.Collections;
import java.util.Enumeration;
import java.util.LinkedHashMap;
import java.util.List;
import java.util.Locale;
import java.util.Map;
import java.util.TimeZone;
import java.util.UUID;

/**
 * Source-level equivalent of the collectors observed in tomu_env_9.trace.
 *
 * This class deliberately uses LinkedHashMap and explicit append order. The native
 * implementation does not sort fields. Empty fields are emitted rather than omitted.
 *
 * Android hidden APIs and package visibility affect several results. Running this in
 * another package/UID cannot reproduce Tomu's privileged visibility or private files.
 */
public final class EnvCollector {
    private static final String PREF = "se_config";
    private static final String PREF_DEVICE_ID = "secure_sharedpreference_id";
    private static final String PREF_SEQUENCE = "secure_local_sequence_id";
    private static final UUID WIDEVINE = new UUID(
            0xedef8ba979d64aceL, 0xa3c827dcd51d21edL);

private EnvCollector() {}

/** Values owned by other Tomu modules or still opaque in the supplied trace. */
    public interface AppInputs {
        String fkResult();             // sample: {"vInfo":...,"antInfo":...}
        String uuid();                 // persisted Tomu UUID, not a fresh UUID each call
        String u2();                   // separate anti-abuse encrypted token
        String cookie();               // sample is a 16-byte value in standard Base64
        String bgid();
        String uidField();
        String field0c1999();
        String field060a12();
        String field01bf33();
        String fieldA5();
        String field74b954();
        String dme();
        String p3();                   // package-service/first-boot status; sample -4
        String p5();
        String p6();
        String p7();
        String p11();
        String p15();                  // sample 900063915; business derivation remains opaque
        String simOperatorDisplay();   // sample 中國移動香港 China Mobile HK
        String socModelOverride();
        String p19PowerProfile();
        String romStatus();
        String didInfo();
        String sequence();
    }

public static final class Defaults implements AppInputs {
        public String fkResult() { return "{\"vInfo\":{\"exits\":0,\"id\":\"\"},\"antInfo\":{\"exits\":0}}"; }
        public String uuid() { return ""; }
        public String u2() { return ""; }
        public String cookie() { return ""; }
        public String bgid() { return ""; }
        public String uidField() { return ""; }
        public String field0c1999() { return ""; }
        public String field060a12() { return ""; }
        public String field01bf33() { return ""; }
        public String fieldA5() { return "1"; }
        public String field74b954() { return ""; }
        public String dme() { return "1"; }
        public String p3() { return "-4"; }
        public String p5() { return ""; }
        public String p6() { return ""; }
        public String p7() { return ""; }
        public String p11() { return ""; }
        public String p15() { return ""; }
        public String simOperatorDisplay() { return ""; }
        public String socModelOverride() { return ""; }
        public String p19PowerProfile() { return ""; }
        public String romStatus() { return ""; }
        public String didInfo() { return ""; }
        public String sequence() { return "0"; }
    }

public static String buildPBlock(Context context, AppInputs in) {
        StringBuilder q = new StringBuilder(8192);
        addRaw(q, "p1", formEncode(collectP1ServiceProbe()));
        addRaw(q, "p2", collectP2KeyStoreChain());
        addRaw(q, "p3", nz(in.p3()));
        addRaw(q, "p4", collectP4KernelJson());
        addRaw(q, "p5", nz(in.p5()));
        addRaw(q, "p6", nz(in.p6()));
        addRaw(q, "p7", nz(in.p7()));
        addRaw(q, "p8", getSetting(context, "boot_count"));
        // Trace shows p9 retained Unicode and spaces; do not encode it here.
        addRaw(q, "p9", nz(in.simOperatorDisplay()));
        addRaw(q, "p10", getAndroidIdViaProviderCall(context));
        addRaw(q, "p11", nz(in.p11()));
        addRaw(q, "p12", collectDefaultSms(context));
        addRaw(q, "p13", formEncode(collectDisplays(context)));
        addRaw(q, "p14", String.valueOf(getInstallerPackage(context)));
        addRaw(q, "p15", nz(in.p15()));
        addRaw(q, "p16", collectAudioJson(context));
        addRaw(q, "p17", collectLocale(context));
        addRaw(q, "p18", collectTimeZone());
        addRaw(q, "p19", nz(in.p19PowerProfile()));
        addRaw(q, "p20", collectSoc(in));
        addRaw(q, "p21", getSetting(context, "ad_aaid"));
        return q.toString();
    }

/** First query observed as one Java string before native collector fields are added. */
    public static String buildMainQuery(Context c, AppInputs in) {
        LinkedHashMap<String, String> m = new LinkedHashMap<>();
        m.put("version", Integer.toString(Build.VERSION.SDK_INT));
        m.put("process_id", Integer.toString(Process.myPid()));
        m.put("availablecapacity", Long.toString(storageAvailable()));
        m.put("input_device", collectInputDevices());
        m.put("machine_arch", machineArch());
        m.put("fk_result", nz(in.fkResult()));
        m.put("0c1999", nz(in.field0c1999()));
        m.put("foreground", Boolean.toString(isForeground(c)));
        m.put("uuid", nz(in.uuid()));
        m.put("secure_lock", collectSecureLock(c));
        m.put("totalcapacity", Long.toString(storageTotal()));
        m.put("mediaDrm", collectWidevine());
        m.put("c86fee", appVersion(c));
        m.put("instrumentation", instrumentationClass());
        m.put("u2", nz(in.u2()));
        m.put("ab9de2", "1");
        m.put("060a12", nz(in.field060a12()));
        m.put("net_type", networkType(c));
        m.put("01bf33", nz(in.field01bf33()));
        m.put("currentTime", Long.toString(System.currentTimeMillis()));
        m.put("availablememory", Long.toString(availableMemory(c)));
        m.put("brightness", screenBrightness(c));
        m.put("a5", nz(in.fieldA5()));
        m.put("74b954", nz(in.field74b954()));
        m.put("kernelVersion", readFirstLine("/proc/version"));
        m.put("eeba5e", Locale.getDefault().getLanguage());
        m.put("02b81e", TimeZone.getDefault().getID());
        m.put("dme", nz(in.dme()));
        return encodeMap(m);
    }

/** Native fields appended after buildMainQuery(), in observed order. */
    public static String appendNativeFields(Context c, String main, AppInputs in) {
        StringBuilder q = new StringBuilder(main);
        addEncoded(q, "platform_type", "1");
        addEncoded(q, "sharedpreference_id", sharedPreferenceId(c));
        addEncoded(q, "dpi", Integer.toString(displayMetrics(c).densityDpi));
        DisplayMetrics dm = displayMetrics(c);
        addEncoded(q, "resolution", dm.widthPixels + "x" + dm.heightPixels);
        addEncoded(q, "uid", nz(in.uidField()));
        addEncoded(q, "cookie", nz(in.cookie()));
        addEncoded(q, "cpuinfo", collectCpuInfo());
        addEncoded(q, "build_id", Build.ID);
        addEncoded(q, "fingerprint", Build.FINGERPRINT);
        addEncoded(q, "battery_status", collectBattery(c));
        addEncoded(q, "boot_time", collectBootInfo());
        addEncoded(q, "root", collectRoot());
        addEncoded(q, "rom_status", nz(in.romStatus()));
        PackageInfo pi = ownPackageInfo(c);
        addEncoded(q, "install_time", pi == null ? "" : Long.toString(pi.firstInstallTime));
        addEncoded(q, "app_update_time", pi == null ? "" : Long.toString(pi.lastUpdateTime));
        // Misspelling is protocol-significant.
        addEncoded(q, "input_mathod", Settings.Secure.getString(c.getContentResolver(), Settings.Secure.DEFAULT_INPUT_METHOD));
        addEncoded(q, "ip_list", collectIpList());
        addEncoded(q, "total_memory", Long.toString(totalMemoryBytes()));
        addEncoded(q, "sequence", nz(in.sequence()));
        addEncoded(q, "local_sequence", Integer.toString(nextLocalSequence(c)));
        addEncoded(q, "did_info", nz(in.didInfo()));
        addEncoded(q, "simState", collectSimState(c));
        addEncoded(q, "bgid", nz(in.bgid()));
        return q.toString();
    }

public static String collectP1ServiceProbe() {
        List<String> services = listServicesHidden();
        String[] suspects = {"oppo", "miui", "vivo", "meizu", "redmi", "xiaomi", "huawei",
                "oneplus", "lineage", "samsung", "xposed", ".leui.", "realme", "asus",
                "blackshark", "meitu", "libsu"};
        List<String> hits = new ArrayList<>();
        for (String service : services) {
            String lower = service.toLowerCase(Locale.ROOT);
            for (String suspect : suspects) {
                if (lower.contains(suspect)) { hits.add(service); break; }
            }
        }
        // Exact key spelling "exits" is intentional and observed in trace.
        return "{\"vInfo\":{\"exits\":" + (hits.isEmpty() ? "0" : "1")
                + ",\"id\":\"\"},\"systemService\":\"" + jsonEscape(hits.toString()) + "\"}";
    }

@SuppressWarnings("unchecked")
    private static List<String> listServicesHidden() {
        try {
            Class<?> sm = Class.forName("android.os.ServiceManager");
            String[] a = (String[]) sm.getDeclaredMethod("listServices").invoke(null);
            List<String> out = new ArrayList<>();
            if (a != null) Collections.addAll(out, a);
            return out;
        } catch (Throwable ignored) { return Collections.emptyList(); }
    }

public static String collectP2KeyStoreChain() {
        for (String alias : new String[]{"tomu_secure_v2", "tomu_secure"}) {
            try {
                KeyStore ks = KeyStore.getInstance("AndroidKeyStore");
                ks.load(null);
                if (!ks.containsAlias(alias)) continue;
                Certificate[] chain = ks.getCertificateChain(alias);
                if (chain == null) continue;
                StringBuilder out = new StringBuilder();
                for (Certificate cert : chain) {
                    out.append(Base64.encodeToString(cert.getEncoded(), Base64.NO_WRAP)).append(';');
                }
                return formEncode(out.toString());
            } catch (Throwable ignored) {}
        }
        return "";
    }

public static String collectP4KernelJson() {
        String procVersion = readFirstLine("/proc/version");
        String uname = exec("uname", "-a").trim();
        // The trace encodes the two values, but leaves JSON punctuation unescaped.
        return "{\"1\":\"" + formEncode(procVersion) + "\",\"2\":\"" + formEncode(uname) + "\"}";
    }

public static String getAndroidIdViaProviderCall(Context c) {
        try {
            ContentResolver r = c.getContentResolver();
            Bundle b = r.call(Uri.parse("content://settings/secure"), "GET_secure", "android_id", null);
            if (b != null) return nz(b.getString("value"));
        } catch (Throwable ignored) {}
        return nz(Settings.Secure.getString(c.getContentResolver(), Settings.Secure.ANDROID_ID));
    }

public static String collectDefaultSms(Context c) {
        try {
            String pkg = Telephony.Sms.getDefaultSmsPackage(c);
            if (pkg == null) return "";
            PackageManager pm = c.getPackageManager();
            PackageInfo pi;
            if (Build.VERSION.SDK_INT >= 28) {
                pi = pm.getPackageInfo(pkg, PackageManager.GET_SIGNING_CERTIFICATES);
            } else {
                pi = pm.getPackageInfo(pkg, PackageManager.GET_SIGNATURES);
            }
            ApplicationInfo ai = pi.applicationInfo;
            String label = ai == null ? "" : ai.loadLabel(pm).toString();
            Signature sig = firstSignature(pi);
            String md5 = sig == null ? "" : md5Upper(sig.toCharsString().getBytes(StandardCharsets.UTF_8));
            long version = Build.VERSION.SDK_INT >= 28 ? pi.getLongVersionCode() : pi.versionCode;
            int flags = ai == null ? 0 : ai.flags;
            return pkg + "|" + label + "|" + md5 + "|" + version + "|" + flags;
        } catch (Throwable ignored) { return ""; }
    }

private static Signature firstSignature(PackageInfo pi) {
        if (Build.VERSION.SDK_INT >= 28 && pi.signingInfo != null) {
            Signature[] s = pi.signingInfo.hasMultipleSigners()
                    ? pi.signingInfo.getApkContentsSigners()
                    : pi.signingInfo.getSigningCertificateHistory();
            return s == null || s.length == 0 ? null : s[0];
        }
        return pi.signatures == null || pi.signatures.length == 0 ? null : pi.signatures[0];
    }

public static String collectDisplays(Context c) {
        try {
            DisplayManager dm = (DisplayManager) c.getSystemService(Context.DISPLAY_SERVICE);
            StringBuilder out = new StringBuilder();
            for (Display d : dm.getDisplays()) {
                String owner = null;
                try {
                    Field f = Display.class.getDeclaredField("mDisplayInfo");
                    f.setAccessible(true);
                    Object info = f.get(d);
                    Field ownerField = info.getClass().getDeclaredField("ownerPackageName");
                    ownerField.setAccessible(true);
                    owner = (String) ownerField.get(info);
                } catch (Throwable ignored) {}
                out.append(d.getName()).append('|').append(String.valueOf(owner)).append(';');
            }
            return out.toString();
        } catch (Throwable ignored) { return ""; }
    }

public static String collectAudioJson(Context c) {
        AudioManager a = (AudioManager) c.getSystemService(Context.AUDIO_SERVICE);
        LinkedHashMap<String,Integer> streams = new LinkedHashMap<>();
        streams.put("voiceCall", AudioManager.STREAM_VOICE_CALL);
        streams.put("system", AudioManager.STREAM_SYSTEM);
        streams.put("ring", AudioManager.STREAM_RING);
        streams.put("music", AudioManager.STREAM_MUSIC);
        streams.put("alarm", AudioManager.STREAM_ALARM);
        streams.put("notification", AudioManager.STREAM_NOTIFICATION);
        StringBuilder s = new StringBuilder("{");
        for (Map.Entry<String,Integer> e : streams.entrySet()) {
            if (s.length() > 1) s.append(',');
            int min = Build.VERSION.SDK_INT >= 28 ? a.getStreamMinVolume(e.getValue()) : 0;
            s.append('"').append(e.getKey()).append("\":{\"min\":").append(min)
                    .append(",\"max\":").append(a.getStreamMaxVolume(e.getValue()))
                    .append(",\"cur\":").append(a.getStreamVolume(e.getValue())).append('}');
        }
        return s.append('}').toString();
    }

public static String collectLocale(Context c) {
        Locale locale;
        if (Build.VERSION.SDK_INT >= 24) {
            LocaleList l = c.getResources().getConfiguration().getLocales();
            locale = l.isEmpty() ? Locale.getDefault() : l.get(0);
        } else locale = c.getResources().getConfiguration().locale;
        String country = locale.getCountry();
        return locale.getLanguage() + (country.isEmpty() ? "" : "_" + country);
    }

public static String collectTimeZone() {
        TimeZone z = TimeZone.getDefault();
        return z.getID() + " " + z.getDisplayName();
    }

public static String collectSoc(AppInputs in) {
        String override = nz(in.socModelOverride());
        if (!override.isEmpty()) return override;
        if (Build.VERSION.SDK_INT >= 31 && Build.SOC_MODEL != null) return Build.SOC_MODEL;
        String[] props = {"ro.soc.model", "ro.board.platform", "ro.hardware"};
        for (String p : props) { String v = systemProperty(p); if (!v.isEmpty()) return v; }
        return Build.HARDWARE;
    }

public static String collectInputDevices() {
        StringBuilder out = new StringBuilder();
        for (int id : InputDevice.getDeviceIds()) {
            InputDevice d = InputDevice.getDevice(id);
            if (d == null) continue;
            out.append(id).append('|').append(d.getName()).append('|')
                    .append(d.getDescriptor()).append('|')
                    .append(d.getVendorId()).append(';');
        }
        return out.toString();
    }

public static boolean isForeground(Context c) {
        ActivityManager am = (ActivityManager)c.getSystemService(Context.ACTIVITY_SERVICE);
        ActivityManager.RunningAppProcessInfo me = new ActivityManager.RunningAppProcessInfo();
        ActivityManager.getMyMemoryState(me);
        return me.importance == ActivityManager.RunningAppProcessInfo.IMPORTANCE_FOREGROUND
                || me.importance == ActivityManager.RunningAppProcessInfo.IMPORTANCE_VISIBLE;
    }

public static String collectSecureLock(Context c) {
        try {
            KeyguardManager k = (KeyguardManager)c.getSystemService(Context.KEYGUARD_SERVICE);
            return k.isDeviceSecure() ? "1" : "0";
        } catch (Throwable ignored) { return "0"; }
    }

public static String collectWidevine() {
        MediaDrm drm = null;
        try {
            drm = new MediaDrm(WIDEVINE);
            String id = sha256Lower(drm.getPropertyByteArray(MediaDrm.PROPERTY_DEVICE_UNIQUE_ID));
            return "0:" + id + "|" + drm.getPropertyString(MediaDrm.PROPERTY_VENDOR)
                    + "|" + drm.getPropertyString(MediaDrm.PROPERTY_VERSION)
                    + "|" + drm.getPropertyString(MediaDrm.PROPERTY_DESCRIPTION) + ";";
        } catch (Throwable ignored) { return ""; }
        finally { if (drm != null) try { drm.close(); } catch (Throwable ignored) {} }
    }

public static String instrumentationClass() {
        try {
            Class<?> at = Class.forName("android.app.ActivityThread");
            Method current = at.getDeclaredMethod("currentActivityThread");
            current.setAccessible(true);
            Object thread = current.invoke(null);
            Field f = at.getDeclaredField("mInstrumentation");
            f.setAccessible(true);
            Object inst = f.get(thread);
            return inst == null ? "" : inst.getClass().getName();
        } catch (Throwable ignored) { return ""; }
    }

public static String collectBattery(Context c) {
        Intent i = c.registerReceiver(null, new IntentFilter(Intent.ACTION_BATTERY_CHANGED));
        if (i == null || i.getExtras() == null) return "";
        // Bundle keySet iteration order is deliberately retained: trace used keySet().iterator().
        StringBuilder out = new StringBuilder();
        Bundle b = i.getExtras();
        for (String key : b.keySet()) {
            Object value = b.get(key);
            out.append(key).append(',').append(String.valueOf(value)).append(',');
        }
        return out.toString();
    }

public static String collectIpList() {
        StringBuilder out = new StringBuilder();
        try {
            Enumeration<NetworkInterface> es = NetworkInterface.getNetworkInterfaces();
            while (es.hasMoreElements()) {
                NetworkInterface ni = es.nextElement();
                if (!ni.isUp()) continue;
                Enumeration<InetAddress> as = ni.getInetAddresses();
                while (as.hasMoreElements()) {
                    InetAddress a = as.nextElement();
                    if (!a.isLoopbackAddress()) out.append(a.getHostAddress()).append(';');
                }
            }
        } catch (Throwable ignored) {}
        return out.toString();
    }

public static String collectRoot() {
        String[] paths = {"/product/bin/su", "/sbin/su", "/system/bin/su", "/system/sbin/su",
                "/system/xbin/su", "/vendor/bin/su", "/data/misc/riru"};
        for (String p : paths) if (new File(p).exists()) return "1";
        return "0";
    }

public static String collectCpuInfo() {
        String cpu = readAll("/proc/cpuinfo");
        for (String line : cpu.split("\\n")) {
            String l = line.toLowerCase(Locale.ROOT);
            if (l.startsWith("hardware") || l.startsWith("model name")) {
                int p = line.indexOf(':');
                if (p >= 0) return line.substring(p + 1).trim();
            }
        }
        return Build.HARDWARE;
    }

public static String collectBootInfo() {
        return exec("cat", "/proc/sys/kernel/random/boot_id").trim();
    }

public static long totalMemoryBytes() {
        try (BufferedReader r = new BufferedReader(new InputStreamReader(new FileInputStream("/proc/meminfo")))) {
            String line;
            while ((line = r.readLine()) != null) {
                if (line.startsWith("MemTotal:")) {
                    String digits = line.replaceAll("[^0-9]", "");
                    return Long.parseLong(digits) * 1024L;
                }
            }
        } catch (Throwable ignored) {}
        return 0;
    }

public static int nextLocalSequence(Context c) {
        SharedPreferences p = c.getSharedPreferences(PREF, Context.MODE_PRIVATE);
        int current = p.getInt(PREF_SEQUENCE, 0);
        p.edit().putInt(PREF_SEQUENCE, current + 1).apply();
        return current;
    }

public static String sharedPreferenceId(Context c) {
        return c.getSharedPreferences(PREF, Context.MODE_PRIVATE).getString(PREF_DEVICE_ID, "");
    }

public static String collectSimState(Context c) {
        try {
            Object tm = c.getSystemService(Context.TELEPHONY_SERVICE);
            Method m = tm.getClass().getMethod("getSimState");
            return Integer.toString((Integer)m.invoke(tm));
        } catch (Throwable ignored) { return "0"; }
    }

private static long storageAvailable() {
        try { return new StatFs(Environment.getDataDirectory().getPath()).getAvailableBytes(); }
        catch (Throwable ignored) { return 0; }
    }

private static long storageTotal() {
        try { return new StatFs(Environment.getDataDirectory().getPath()).getTotalBytes(); }
        catch (Throwable ignored) { return 0; }
    }

private static long availableMemory(Context c) {
        ActivityManager.MemoryInfo m = new ActivityManager.MemoryInfo();
        ((ActivityManager)c.getSystemService(Context.ACTIVITY_SERVICE)).getMemoryInfo(m);
        return m.availMem;
    }

private static DisplayMetrics displayMetrics(Context c) {
        DisplayMetrics dm = new DisplayMetrics();
        WindowManager wm = (WindowManager)c.getSystemService(Context.WINDOW_SERVICE);
        wm.getDefaultDisplay().getRealMetrics(dm);
        return dm;
    }

private static String screenBrightness(Context c) {
        try { return Integer.toString(Settings.System.getInt(c.getContentResolver(), Settings.System.SCREEN_BRIGHTNESS)); }
        catch (Throwable ignored) { return ""; }
    }

private static String machineArch() {
        String abi = Build.SUPPORTED_ABIS.length == 0 ? "" : Build.SUPPORTED_ABIS[0].toLowerCase(Locale.ROOT);
        if (abi.contains("arm")) return "ARM";
        if (abi.contains("x86")) return "X86";
        return abi.toUpperCase(Locale.ROOT);
    }

private static String networkType(Context c) {
        try {
            ConnectivityManager cm = (ConnectivityManager)c.getSystemService(Context.CONNECTIVITY_SERVICE);
            Network n = cm.getActiveNetwork();
            NetworkCapabilities nc = cm.getNetworkCapabilities(n);
            if (nc == null) return "NONE";
            if (nc.hasTransport(NetworkCapabilities.TRANSPORT_WIFI)) return "WIFI";
            if (nc.hasTransport(NetworkCapabilities.TRANSPORT_CELLULAR)) return "MOBILE";
            if (nc.hasTransport(NetworkCapabilities.TRANSPORT_ETHERNET)) return "ETHERNET";
        } catch (Throwable ignored) {}
        return "UNKNOWN";
    }

private static String appVersion(Context c) {
        PackageInfo p = ownPackageInfo(c);
        return p == null ? "" : nz(p.versionName);
    }

private static PackageInfo ownPackageInfo(Context c) {
        try { return c.getPackageManager().getPackageInfo(c.getPackageName(), 0); }
        catch (Throwable ignored) { return null; }
    }

private static String getInstallerPackage(Context c) {
        try {
            if (Build.VERSION.SDK_INT >= 30) {
                InstallSourceInfo s = c.getPackageManager().getInstallSourceInfo(c.getPackageName());
                return s.getInstallingPackageName();
            }
            return c.getPackageManager().getInstallerPackageName(c.getPackageName());
        } catch (Throwable ignored) { return null; }
    }

private static String getSetting(Context c, String key) {
        String v = null;
        try { v = Settings.Global.getString(c.getContentResolver(), key); } catch (Throwable ignored) {}
        if (v == null) try { v = Settings.Secure.getString(c.getContentResolver(), key); } catch (Throwable ignored) {}
        return nz(v);
    }

private static String systemProperty(String key) {
        try {
            Class<?> c = Class.forName("android.os.SystemProperties");
            return nz((String)c.getDeclaredMethod("get", String.class).invoke(null, key));
        } catch (Throwable ignored) { return ""; }
    }

private static String encodeMap(LinkedHashMap<String,String> map) {
        StringBuilder q = new StringBuilder();
        for (Map.Entry<String,String> e : map.entrySet()) addEncoded(q, e.getKey(), e.getValue());
        return q.toString();
    }

private static void addEncoded(StringBuilder q, String key, String value) {
        if (q.length() != 0) q.append('&');
        q.append(key).append('=').append(formEncode(nz(value)));
    }

private static void addRaw(StringBuilder q, String key, String alreadyEncodedOrRawValue) {
        if (q.length() != 0) q.append('&');
        q.append(key).append('=').append(nz(alreadyEncodedOrRawValue));
    }

/** java.net.URLEncoder semantics observed in trace: UTF-8 and spaces represented by '+'. */
    public static String formEncode(String s) {
        try { return URLEncoder.encode(nz(s), "UTF-8"); }
        catch (Throwable ignored) { return nz(s); }
    }

private static String md5Upper(byte[] bytes) throws Exception {
        return hex(MessageDigest.getInstance("MD5").digest(bytes), true);
    }

private static String sha256Lower(byte[] bytes) throws Exception {
        return hex(MessageDigest.getInstance("SHA-256").digest(bytes), false);
    }

private static String hex(byte[] bytes, boolean upper) {
        char[] alphabet = (upper ? "0123456789ABCDEF" : "0123456789abcdef").toCharArray();
        char[] out = new char[bytes.length * 2];
        for (int i=0;i<bytes.length;i++) { out[i*2]=alphabet[(bytes[i]>>>4)&15]; out[i*2+1]=alphabet[bytes[i]&15]; }
        return new String(out);
    }

private static String readFirstLine(String path) {
        try (BufferedReader r = new BufferedReader(new InputStreamReader(new FileInputStream(path)))) {
            return nz(r.readLine());
        } catch (Throwable ignored) { return ""; }
    }

private static String readAll(String path) {
        try (InputStream in = new FileInputStream(path); ByteArrayOutputStream out = new ByteArrayOutputStream()) {
            byte[] b = new byte[4096]; int n;
            while ((n=in.read(b))>=0) out.write(b,0,n);
            return out.toString("UTF-8");
        } catch (Throwable ignored) { return ""; }
    }

private static String exec(String... argv) {
        try {
            java.lang.Process p = new ProcessBuilder(argv).redirectErrorStream(true).start();
            ByteArrayOutputStream out = new ByteArrayOutputStream();
            try (InputStream in = p.getInputStream()) { byte[] b=new byte[1024]; int n; while((n=in.read(b))>=0) out.write(b,0,n); }
            p.waitFor();
            return out.toString("UTF-8");
        } catch (Throwable ignored) { return ""; }
    }

private static String jsonEscape(String s) {
        return nz(s).replace("\\", "\\\\").replace("\"", "\\\"");
    }

private static String nz(String s) { return s == null ? "" : s; }
}

```

---

# 最终复现调用示例

```java
EnvCollector.AppInputs inputs = new EnvCollector.Defaults() {
    @Override public String uuid() {
        return loadOriginalTomuUuid();
    }

@Override public String u2() {
        return generateOriginalU2Token();
    }

@Override public String cookie() {
        return loadOriginalCookie();
    }

@Override public String p15() {
        return calculateOriginalP15();
    }

@Override public String didInfo() {
        return buildOriginalDidInfo();
    }
};

String pBlock = EnvCollector.buildPBlock(context, inputs);
String javaMainQuery = EnvCollector.buildMainQuery(context, inputs);
String nativePlaintext = EnvCollector.appendNativeFields(
        context, javaMainQuery, inputs);

// pBlock 由更高层调用方放入对应业务参数；nativePlaintext 是本 trace
// 中进入最终 native 加密信封的数据主体。
```

# 完整性结论

- 已给出所有已观察字段的 Java 源码级采集方法。
- 已给出字段的协议名称、顺序、空值处理、内部连接符及 URL 编码规则。
- 已给出 `p1`～`p21`、Java 主 query 和 native 后续字段三部分实现。
- 已给出最终二进制加密信封的长度公式和 native 函数地址。
- 已明确标注当前 trace 没有覆盖 producer 的业务输入；这些字段必须接入原 Tomu 模块后才能做到完全相同的值。
- 在不同包名或不同 UID 下运行，只能复现采集语义，无法读取 Tomu 的 Android Keystore alias、SharedPreferences 和其他私有状态。

回复或点赞可查看完整内容

传递专业知识、拓宽行业人脉——看雪讲师团队等你加入！！

最新回复 (15)
墨穹呢雪币： 4788 活跃值： (8257) 能力值： ( LV3，RANK：20 ) 在线值：发帖 2 回帖 234 粉丝 18 关注私信	墨穹呢 2 楼感谢分享！ 14小时前 0
mb_asiwnxyv 雪币： 6 能力值： ( LV1，RANK：0 ) 在线值：发帖 0 回帖 101 粉丝 0 关注私信	mb_asiwnxyv 3 楼 6666 12小时前 0
烬奇小云雪币： 778 活跃值： (3692) 能力值： ( LV3，RANK：20 ) 在线值：发帖 7 回帖 84 粉丝 18 关注私信	烬奇小云 4 楼 666 12小时前 0
koflfy 雪币： 102 活跃值： (4161) 能力值： ( LV4，RANK：50 ) 在线值：发帖 8 回帖 486 粉丝 5 关注私信	koflfy 1 5 楼我去，乐哥出品，前排占位。 12小时前 0
不知世事雪币： 3712 活跃值： (2701) 能力值： ( LV5，RANK：70 ) 在线值：发帖 3 回帖 199 粉丝 14 关注私信	不知世事 1 6 楼 1 11小时前 0
xautzbl_270908 雪币： 0 活跃值： (140) 能力值： ( LV2，RANK：10 ) 在线值：发帖 0 回帖 5 粉丝 0 关注私信	xautzbl_270908 7 楼 1 11小时前 0
xianhuimin 雪币： 9359 活跃值： (6263) 能力值： ( LV2，RANK：10 ) 在线值：发帖 5 回帖 234 粉丝 2 关注私信	xianhuimin 8 楼 666 11小时前 0
xingbing 雪币： 158 活跃值： (5841) 能力值： ( LV2，RANK：10 ) 在线值：发帖 2 回帖 1407 粉丝 2 关注私信	xingbing 9 楼感谢分享。 11小时前 0
iBa0 雪币： 1901 活跃值： (5983) 能力值： ( LV4，RANK：40 ) 在线值：发帖 6 回帖 497 粉丝 37 关注私信	iBa0 10 楼 1123 8小时前 0
kingking888 雪币： 3245 活跃值： (6359) 能力值： ( LV2，RANK：10 ) 在线值：发帖 0 回帖 305 粉丝 6 关注私信	kingking888 11 楼 666 8小时前 0
mb_ldbucrik 雪币： 6 能力值： ( LV1，RANK：0 ) 在线值：发帖 0 回帖 714 粉丝 7 关注私信	mb_ldbucrik 12 楼太强了 8小时前 0
mb_ykavguun 雪币： 1328 活跃值： (1860) 能力值： ( LV2，RANK：10 ) 在线值：发帖 0 回帖 168 粉丝 0 关注私信	mb_ykavguun 13 楼 666 8小时前 0
Zepp7289 雪币： 200 能力值： ( LV1，RANK：0 ) 在线值：发帖 1 回帖 154 粉丝 0 关注私信	Zepp7289 14 楼 tql 7小时前 0
蜡笔晓辉雪币： 1200 活跃值： (755) 能力值： ( LV2，RANK：10 ) 在线值：发帖 0 回帖 51 粉丝 2 关注私信	蜡笔晓辉 15 楼 666 6小时前 0
温泉划水鱼雪币： 95 能力值： ( LV1，RANK：0 ) 在线值：发帖 6 回帖 229 粉丝 28 关注私信	温泉划水鱼 16 楼 777 2小时前 0
	游客登录 \| 注册方可回帖回帖表情雪币赚取及消费高级回复
