ollvm一直是程序保护中的一种强有力的手段，将原本的控制流打散，用一套分发器去控制流程（网上资料很多，这里不再赘述，请了解ollvm的基础知识再来阅读此文章，比如啥是序言，啥是后继，啥是分发器），本文将着重于一些被别人忽略的细节，让你能够用一套通法根据不同的变异ollvm特征写出不同的脚本
静态的对抗手段有一些ida插件，比如d810，但是这些静态处理的方法在面对变异ollvm时就显得有些乏力，比如双循环头，汇聚块与循环头合并等问题
我们不经想既然是控制流混淆，那么动态执行一遍找到正确的执行顺序不久行了嘛？

第一步我们就是要找出所有的代码，也就是真实块，我们可以根据一套固定流程来确定寻找
先祭出老生常谈的一张图

假如说又回到了B，那么B就是循环头，我们根据BFS算法可以找出来

循环头有两个前驱，一个是序言，用与开辟栈空间，初始化变量之类的，一个是汇聚块
怎么判断哪个是汇聚块呢？汇聚块有很多前驱，而哪些前驱就是我们最关心的————真实快
ps:其实序言也是真实块之一，别忘了（

这里也是考虑了多循环头的情况，可以自己看情况改
我们以[RoarCTF 2019]polyre 为例子，附件和所有脚本我都放github上了
cbdK9s2c8@1M7s2y4Q4x3@1q4Q4x3V1k6Q4x3V1k6Y4K9i4c8Z5N6h3u0Q4x3X3g2U0L8$3#2Q4x3V1k6c8L8h3g2A6L8h3g2A6x3e0l9H3z5o6k6Q4x3V1k6V1k6h3k6D9j5i4c8Q4x3X3c8S2L8X3N6J5
ida运行结果是

这就到了本文最精髓的地方了，我们要找到每个块的后继
对于每一个真实块，我们遵循一套这样的法则
序言执 -> 主分发器 -> 直接跳到我们要的真实块 -> 继续执行看会到哪一个块
重点:

cmovxx通过修改寄存器的值，影响上面分发器的分发，达到不同的块
但是我们angr遇到不会cmovxx这些汇编分裂出两个分支，而是通过积累一个约束实现，所以我们要手动分裂两个状态，一个执行这条，一个不执行，就会到达两不同的块，然后我们这样储存

左边放我们zf=1的,右边放zf=0的，方便我们接下来patch

几个关键点

我们通过hook主分发器的最后一个指令，运行到直接跳到我们要的块，然后记得unhook，不然到时候执行回来又跳到那里去了，就循环了
为什么要 -6，我只能说理论上应该不用加偏移，但是实际上不加的化angr不能正确的识别指令，capstone解码出来的混乱的，这个-6是我摸索出来的，如果不行你们可以试试别的，记得把汇编输出出来对一下就行（我把它注释了）
运行结果

剩下的地方用nop填充
然后再后面把没用到的块给nop了

这里一个小细节,我们先找出所有的无用块列表，得到开始地址与结束地址，然后在进行控制流的patch，最后根据前面获取的无用块列表，nop无用块，如果先patch控制流在寻找无用块，找出来的无用块是错误的
恢复完的到代码

最后exp:

A -> B -> C -> D -> B

# ida python
def find_loop_head(start_ea):
    loop_heads = set()
    queue = deque() # BFS 队列
    blcok = get_basic_block(start_ea) # 获取起始地址所在的基本块
    queue.append((blcok,[]))
    while len(queue) > 0:
        cur_block, path = queue.popleft()
        if cur_block.start_ea in path:
            loop_heads.add(cur_block.start_ea) # 找到循环头
            continue
        path = path + [cur_block.start_ea] # 更新路径
        queue.extend((s, path) for s in cur_block.succs()) # 将后继加入队列

    all_loop_heads = list(loop_heads)
    all_loop_heads.sort() # 升序排序，确保主循环头在第一个
    print("[+]Find loop heads:",[hex(lh) for lh in all_loop_heads]," -- total:",len(all_loop_heads))
    return all_loop_heads

def find_converge_addr(loop_head_addr):
    converge_addr = 0
    block = get_basic_block(loop_head_addr) # 循环头
    preds = block.preds() # 获取前驱基本块
    pred_list = list(preds)

    if len(pred_list) == 2: # 标准 ollvm：循环头有两个前驱,一个序言块一个汇聚块
        for pred in pred_list:
            tmp_list = list(pred.preds())
            if len(tmp_list) > 1: # 有多个前驱的块是汇聚块
                converge_addr = pred.start_ea
    print("[+]Find converge_addr:",hex(converge_addr))
    return converge_addr

    for loop_head_addr in loop_heads:
        loop_head_block = get_basic_block(loop_head_addr)
        converge_addr = find_converge_addr(loop_head_addr)
        real_blocks = []


        #找出序言
        loop_head_preds = list(loop_head_block.preds())
        loop_head_preds_addr = [b.start_ea for b in loop_head_preds]
        if loop_head_addr != converge_addr:
            loop_head_preds_addr.remove(converge_addr)
            print("序言块:",[hex(x) for x in loop_head_preds_addr])

def find_ret_block(blocks):
    for block in blocks:
        succs = list(block.succs()) # 获取后继块
        succs_list = list(succs)

        end_ea = block.end_ea # end_ea 指向基本块最后一条指令的下一个地址
        last_inst_ea = idc.prev_head(end_ea) # 获取基本块最后一条指令地址
        mnem = idc.print_insn_mnem(last_inst_ea) # 获取指令助记符

        if len(succs_list) == 0: # 没有后继块
            if mnem == "retn": # 最后一条指令是 ret 指令
                ori_ret_block = block

                # 向上寻找更合适的 ret 块
                while True:
                    tmp_block = block.preds()
                    pred_list = list(tmp_block)
                    if len(pred_list) == 1: # 只有一个前驱
                        block = pred_list[0]
                        if get_block_size(block) == 4: # 单指令块
                            continue
                        else:
                            break
                    else: # 多个前驱或者无前驱
                        break

                # 处理子分发器情况
                block2 = block
                num = 0
                i = 0
                while True:
                    i += 1
                    succs_block = block2.succs()
                    for succ in succs_block:
                        child_succs = succ.succs()
                        succ_list = list(child_succs)
                        if len(succ_list) != 0:
                            block2 = succ
                            num += 1
                    if num > 2:
                        block = ori_ret_block
                        break
                    if i > 2:
                        break
                print("[+]ret块",hex(block.start_ea))
                return block.start_ea
# 这里是是考虑了可能ret块有前驱，保险起见算一起，可以不用这么多，当然这个代码你直接抄去就行，你可以先自己观察一下哦，有时候自己找ret块也行

def find_all_real_blocks(fun_ea):
    blocks = idaapi.FlowChart(idaapi.get_func(fun_ea))
    loop_heads = find_loop_head(fun_ea)
    all_real_blocks = []


    for loop_head_addr in loop_heads:
        loop_head_block = get_basic_block(loop_head_addr)
        converge_addr = find_converge_addr(loop_head_addr)
        real_blocks = []


        #找出序言
        loop_head_preds = list(loop_head_block.preds())
        loop_head_preds_addr = [b.start_ea for b in loop_head_preds]
        if loop_head_addr != converge_addr:
            loop_head_preds_addr.remove(converge_addr)
            print("序言块:",[hex(x) for x in loop_head_preds_addr])
            real_blocks.extend(loop_head_preds_addr)

        converge_block = get_basic_block(converge_addr)
        list_preds = list(converge_block.preds())




        for pred in list_preds:
            end_ea = pred.end_ea
            last_inst_ea = idc.prev_head(end_ea)
            mnem = idc.print_insn_mnem(last_inst_ea)

            size = get_block_size(pred)
            if size > 5: # 大于单指令块且不是跳转指令
                start_ea = pred.start_ea
                real_blocks.append(start_ea)

        real_blocks.sort() # 排序，第一个是序言块
        all_real_blocks.append(real_blocks)

        print("子循环头及其子真实块", [hex(child_block_ea) for child_block_ea in real_blocks])

    ret_addr = find_ret_block(blocks)
    all_real_blocks.append(ret_addr)
    print("all_real_blocks:",all_real_blocks)


    all_real_block_list = []
    for real_blocks in all_real_blocks:
        if isinstance(real_blocks,list):
            all_real_block_list.extend(real_blocks)
        else:
            all_real_block_list.append(real_blocks)

    print(f"\n所有真实块获取完成 真实块数量: {len(all_real_block_list)}")
    print(all_real_block_list)

[+]Find loop heads: ['0x40063f']  -- total: 1
[+]Find converge_addr: 0x4020cc
序言块: ['0x400620']
子循环头及其子真实块 ['0x400620', '0x401121', '0x401198', '0x4011de', '0x40124f', '0x40125e', '0x4012a4', '0x4012f6', '0x401305', '0x401326', '0x40136c', '0x4013b2', '0x4013cf', '0x4013ef', '0x401435', '0x401481', '0x401490', '0x4014ae', '0x4014d2', '0x4014e8', '0x4014f7', '0x401506', '0x401521', '0x401567', '0x4015b6', '0x4015c5', '0x4015d4', '0x4015ed', '0x4015fc', '0x401642', '0x401691', '0x4016a0', '0x4016e6', '0x401739', '0x401748', '0x401765', '0x4017ab', '0x4017fc', '0x40180b', '0x401830', '0x401849', '0x401861', '0x4018a7', '0x4018fa', '0x401909', '0x401926', '0x401940', '0x401960', '0x40197d', '0x40199b', '0x4019e1', '0x401a3d', '0x401a4c', '0x401a73', '0x401a8d', '0x401ad3', '0x401b25', '0x401b34', '0x401b4e', '0x401b5d', '0x401b75', '0x401bbb', '0x401c0d', '0x401c1c', '0x401c2b', '0x401c46', '0x401c69', '0x401caf', '0x401d03', '0x401d12', '0x401d2d', '0x401d45', '0x401d54', '0x401d9a', '0x401e00', '0x401e0f', '0x401e2d', '0x401e73', '0x401eb9', '0x401ed6', '0x401efa', '0x401f09', '0x401f2d', '0x401f3c', '0x401f60', '0x401f97', '0x401fa6', '0x401fb5', '0x401fcd', '0x401fe5', '0x401ff4', '0x40200c', '0x40201b', '0x402033', '0x40204d', '0x402072', '0x402096', '0x4020b3', '0x4020c2']
[+]ret块 0x401f54
all_real_blocks: [[4195872, 4198689, 4198808, 4198878, 4198991, 4199006, 4199076, 4199158, 4199173, 4199206, 4199276, 4199346, 4199375, 4199407, 4199477, 4199553, 4199568, 4199598, 4199634, 4199656, 4199671, 4199686, 4199713, 4199783, 4199862, 4199877, 4199892, 4199917, 4199932, 4200002, 4200081, 4200096, 4200166, 4200249, 4200264, 4200293, 4200363, 4200444, 4200459, 4200496, 4200521, 4200545, 4200615, 4200698, 4200713, 4200742, 4200768, 4200800, 4200829, 4200859, 4200929, 4201021, 4201036, 4201075, 4201101, 4201171, 4201253, 4201268, 4201294, 4201309, 4201333, 4201403, 4201485, 4201500, 4201515, 4201542, 4201577, 4201647, 4201731, 4201746, 4201773, 4201797, 4201812, 4201882, 4201984, 4201999, 4202029, 4202099, 4202169, 4202198, 4202234, 4202249, 4202285, 4202300, 4202336, 4202391, 4202406, 4202421, 4202445, 4202469, 4202484, 4202508, 4202523, 4202547, 4202573, 4202610, 4202646, 4202675, 4202690], 4202324]

loc_40199B:
mov     eax, ds:dword_603054
mov     ecx, ds:dword_603058
mov     edx, eax
sub     edx, 1
imul    eax, edx
and     eax, 1
cmp     eax, 0
setz    sil
cmp     ecx, 0Ah
setl    dil
or      sil, dil
test    sil, 1
mov     eax, 0F37184F0h
mov     ecx, 0A105D2C4h
cmovnz  ecx, eax
mov     [rbp+var_114], ecx
jmp     loc_4020CC

{'0xaaaa':['0xbbb','0xccc']}

import logging
import angr
from tqdm import tqdm

logging.getLogger('angr').setLevel(logging.ERROR)

def capstone_decode_cmovxx(insn):
    operands = insn.op_str.replace(" ", "").split(",")
    dst_reg = operands[0]
    src_reg = operands[1]
    print(f"cmovxx解析结果: 目标寄存器:{dst_reg}, 源寄存器:{src_reg}")
    return dst_reg, src_reg

def find_state_succ_cmovxx(proj, base, local_state, flag, real_blocks, real_block_addr, path):
    # 仅在 find_block_succ 识别为 cmov 时调用
    ins = local_state.block().capstone.insns[0]
    dst_reg, src_reg = capstone_decode_cmovxx(ins)

    # 逻辑修正：
    # flag == True  -> ZF=1 (Zero) -> cmovnz (Not Zero) 条件不满足 -> 不执行 Move -> Pass
    # flag == False -> ZF=0 (Not Zero) -> cmovnz (Not Zero) 条件满足 -> 执行 Move

    if not flag: # 需要执行 Move
        try:
            # 修正：state.regs 没有 .get() 方法，用 getattr
            src_val = getattr(local_state.regs, src_reg)
            setattr(local_state.regs, dst_reg, src_val)
        except Exception as e:
            print(f"寄存器访问错误: {e}")

    # 关键修正：手动跳过这条 cmov 指令！防止 Angr 再次执行它
    local_state.regs.ip += ins.size

    sm = proj.factory.simgr(local_state)

    while(len(sm.active)):
        for active_state in sm.active:
            try:
                ins_offset = active_state.addr - base
                if ins_offset in real_blocks:
                    value = path[real_block_addr]
                    if ins_offset not in value:
                        value.append(ins_offset)
                    return ins_offset
            except:
                pass
        sm.step(num_inst=1)


def find_block_succ(proj, base, func_offset, state, real_block_addr, real_blocks, path):
    msm = proj.factory.simgr(state)  # 构造模拟器
    while len(msm.active):
        for active_state in msm.active:
            #print(active_state.block().capstone.insns[0])
            offset = active_state.addr - base
            #print("当前偏移地址:", hex(offset),"寻找真实块:", hex(real_block_addr))
            if offset == real_block_addr:  # 找到真实块
                print("找到真实块:", hex(real_block_addr))
                mstate = active_state.copy()  # 复制state,为后继块的获取做准备
                msm2 = proj.factory.simgr(mstate)
                msm2.step(num_inst=1)  # 让状态进到块内的下一条指令位置，避免和外层状态混淆

                while len(msm2.active):

                    for mactive_state in msm2.active:
                        #print(mactive_state.block().capstone.insns[0])
                        ins_offset = mactive_state.addr - base
                        if ins_offset in real_blocks:  # 无分支块（或无条件跳转）
                            # 在无条件跳转中,并且有至少两条路径同时执行到真实块时,取非ret块的真实块
                            msm2_len = len(msm2.active)
                            if msm2_len > 1:
                                tmp_addrs = []
                                for s in msm2.active:
                                    moffset = s.addr - base
                                    tmp_value = path[real_block_addr]
                                    if moffset in real_blocks and moffset not in tmp_value:
                                        tmp_addrs.append(moffset)
                                if len(tmp_addrs) > 1:
                                    print("当前至少有两个路径同时执行到真实块:", [hex(tmp_addr) for tmp_addr in tmp_addrs])
                                    ret_addr = real_blocks[len(real_blocks) - 1]
                                    if ret_addr in tmp_addrs:
                                        tmp_addrs.remove(ret_addr)
                                    ins_offset = tmp_addrs[0]
                                    print("两个路径同时执行到真实块最后取得:", hex(ins_offset))

                            value = path[real_block_addr]
                            if ins_offset not in value:
                                value.append(ins_offset)
                            print(f"无条件跳转块关系:{hex(real_block_addr)}-->{hex(ins_offset)}")
                            return
                        # 可能是 cmovnz 分支指令
                        ins = mactive_state.block().capstone.insns[0]
                        if ins.mnemonic == 'cmovnz' or ins.mnemonic == 'cmovne':
                            print("发现 cmovnz/cmovne 指令，进行分支处理:", hex(ins_offset))
                            #分裂双情况
                            state_true = mactive_state.copy()
                            state_true_succ_addr = find_state_succ_cmovxx(proj, base, state_true, True, real_blocks, real_block_addr, path)

                            state_false = mactive_state.copy()
                            state_false_succ_addr = find_state_succ_cmovxx(proj, base, state_false, False, real_blocks, real_block_addr, path)
                            if state_true_succ_addr is None or state_false_succ_addr is None:
                                print("cmovnz/cmovne错误指令地址:", hex(ins_offset))
                                print(f"cmovnz/cmovne后继有误:{hex(real_block_addr)}-->{hex(state_true_succ_addr) if state_true_succ_addr is not None else state_true_succ_addr},"
                                      f"{hex(state_false_succ_addr) if state_false_succ_addr is not None else state_false_succ_addr}")
                                return "erro"
                        #cmovne
                            print(f"cmovnz/cmovne分支跳转块关系:{hex(real_block_addr)}-->{hex(state_true_succ_addr)} zf = 1,  {hex(state_false_succ_addr)} zf != 1")
                            #print(f"csel分支跳转块关系:{hex(real_block_addr)}-->{hex(state_true_succ_addr)},{hex(state_false_succ_addr)}")
                            return
                        #与cmovnz相反
                        if ins.mnemonic == 'cmovz' or ins.mnemonic == 'cmove':
                            print("发现 cmovz/cmove 指令，进行分支处理:", hex(ins_offset))
                            state_true = mactive_state.copy()
                            state_true_succ_addr = find_state_succ_cmovxx(proj, base, state_true, False, real_blocks, real_block_addr, path)

                            state_false = mactive_state.copy()
                            state_false_succ_addr = find_state_succ_cmovxx(proj, base, state_false, True, real_blocks, real_block_addr, path)
                            if state_true_succ_addr is None or state_false_succ_addr is None:
                                print("cmovz/cmove误指令地址:", hex(ins_offset))
                                print(f"cmovz/cmove后继有误:{hex(real_block_addr)}-->{hex(state_true_succ_addr) if state_true_succ_addr is not None else state_true_succ_addr},"
                                      f"{hex(state_false_succ_addr) if state_false_succ_addr is not None else state_false_succ_addr}")
                                return "erro"
                        #cmovne
                            print(f"cmovz/cmove分支跳转块关系:{hex(real_block_addr)}-->{hex(state_true_succ_addr)} zf = 1,  {hex(state_false_succ_addr)} zf != 1")
                            #print(f"csel分支跳转块关系:{hex(real_block_addr)}-->{hex(state_true_succ_addr)},{hex(state_false_succ_addr)}")
                            return

                    msm2.step(num_inst=1)
                # 真实块集合中的最后一个基本块如果最后没找到后继,说明是return块,直接返回
                return
        msm.step(num_inst=1)

def angr_main(real_blocks,func_offset,file_path):
    proj = angr.Project(file_path, auto_load_libs=False)
    base = 0
    func_addr = base + func_offset
    init_state = proj.factory.blank_state(addr=func_addr)
    init_state.options.add(angr.options.CALLLESS)



    path = {addr: [] for addr in real_blocks}

    ret_addr = real_blocks[len(real_blocks) - 1]

    first_block = proj.factory.block(func_addr)
    first_block_insns = first_block.capstone.insns
    # 主序言的最后一条指令
    first_block_last_ins = first_block_insns[len(first_block_insns) - 1]
    print(hex(first_block_last_ins.address))


    for real_block_addr in tqdm(real_blocks):
        if ret_addr == real_block_addr:
            continue

        state = init_state.copy()
        print("正在寻找:",hex(real_block_addr))

        def jump_to_address(state):
            #print(state.regs.pc)

            state.regs.pc = base + real_block_addr - 6
            print("跳转到地址:", hex(base + real_block_addr - 6))
            proj.unhook(0x400675)
        print(hex(real_block_addr),hex(func_offset))

        if real_block_addr != func_offset:
            print("序言结束")
            proj.hook(0x400675, jump_to_address, first_block_last_ins.size)

        ret = find_block_succ(proj, base, func_offset, state, real_block_addr, real_blocks, path)

        if ret == "erro":
            return

    hex_dict = {
        hex(key): [hex(value) for value in values]
        for key, values in path.items()
    }

    for i in hex_dict.keys():
        print(f"{i}:  {hex_dict[i]}")
    print(hex_dict)
    return hex_dict

all_real_blocks: list[int] =[4195872, 4198689, 4198808, 4198878, 4198991, 4199006, 4199076, 4199158, 4199173, 4199206, 4199276, 4199346, 4199375, 4199407, 4199477, 4199553, 4199568, 4199598, 4199634, 4199656, 4199671, 4199686, 4199713, 4199783, 4199862, 4199877, 4199892, 4199917, 4199932, 4200002, 4200081, 4200096, 4200166, 4200249, 4200264, 4200293, 4200363, 4200444, 4200459, 4200496, 4200521, 4200545, 4200615, 4200698, 4200713, 4200742, 4200768, 4200800, 4200829, 4200859, 4200929, 4201021, 4201036, 4201075, 4201101, 4201171, 4201253, 4201268, 4201294, 4201309, 4201333, 4201403, 4201485, 4201500, 4201515, 4201542, 4201577, 4201647, 4201731, 4201746, 4201773, 4201797, 4201812, 4201882, 4201984, 4201999, 4202029, 4202099, 4202169, 4202198, 4202234, 4202249, 4202285, 4202300, 4202336, 4202391, 4202406, 4202421, 4202445, 4202469, 4202484, 4202508, 4202523, 4202547, 4202573, 4202610, 4202646, 4202675, 4202690, 4202324]


angr_main(all_real_blocks, 0x400620, "D:\\reverse\\Angr\\polyre")

def jump_to_address(state):
    #print(state.regs.pc)

    state.regs.pc = base + real_block_addr - 6
    print("跳转到地址:", hex(base + real_block_addr - 6))
    proj.unhook(0x400675)

传递专业知识、拓宽行业人脉——看雪讲师团队等你加入！！
